2231-116/026-000 WAGO Industrial Automation Components

WAGO 2231-116/026-000 is a connector part of the MCS - MULTI CONNECTION SYSTEM, designed without breaking capacity as per DIN EN 61984, indicating it should not be connected or disconnected under load or when live. It adheres to IEC/EN 60664-1 standards, with nominal voltages of 320V and 630V under different conditions, rated impulse voltage of 4kV, and a rated current of 16A. UL and CSA approvals include ratings of up to 600V and 15A under various use groups. This part features 16 connection points, supports a single connection type with push-in CAGE CLAMP technology, and push-button actuation. It accommodates solid and fine-stranded conductors ranging from 0.2 to 2.5mm2 (24 to 12 AWG), with specific allowances for ferruled conductors. The connector has a pin spacing of 5mm, dimensions of 81.5mm in width, 15mm in height, and 25.6mm in depth, and includes features like variable coding and anti-rotation protection. The female connector/socket is made from Polyamide (PA66) with a flammability class of UL94 V0, and the contacts are a copper alloy with tin plating. It operates within a temperature range of -60 to +100°C, has a fire load of 0.604MJ, and weighs 25.2g. The product is RoHS compliant, packaged in boxes of 25 pieces, and has a country of origin of PL.
