261-324/331-000 WAGO Terminal Blocks
Part#:261-324/331-000
Manufacturer:WAGO
Category:Terminal Blocks
Product Lifecycle:Active
Product description
261-324/331-000 WAGO - Space-saving, 2-conductor end terminal block; on one side with push-button; suitable for Ex i applications; without protruding snap-in mounting foot; 1-pole; for terminal strips with snap-in mounting feet; 2.5 mm²; CAGE CLAMP®; 2,50 mm²; blue
Product Details
- Weight 2.203000579 g
- Country Of Origin Germany
- HTS Code 85369010000
- Flammability Class V0
- Operating Temperature 105 degrees celsius
- Color Blue
- Conductor Material Copper
- Voltage 500 volts
- Width 0.236 inches, 6 millimeters
- Country of Origin Germany
- Current 24 amperes
- Mounting Type Snap-in Foot
- Strip Length 0.35 inches, 9 millimeters
- Conductor Size 14 american wire gauge, 2.5 millimeters
- Depth 1.106 inches, 28.1 millimeters
- Package Type Box
- Weight 2.203 grams
- Actuator Operating Tool
- Insulation Material Polyamide
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 261-324/331-000 on Powermatic Associates is $1.01. Order now.
About the product
Wago 261-324/331-000 is a terminal designed for space-saving neutral-through end terminal block applications. It features CAGE-CLAMP spring connections for secure and maintenance-free wiring and is rated for a current of 24A according to IEC standards. This 1-deck/level terminal block offers button operation on one side, side/lateral wire entry, and is suitable for Ex I applications. It has a net height of 6 kV, a rated impulse voltage (Uimp) of 6 mm, and a neutral-through pole (N) for its net width. The terminal block is designed to mount on DIN rails or surfaces via an accessory snap-in foot, comes in blue, and has dimensions of H23.3mm x W6mm x D28.1mm. It accommodates 0.08mm2 to 2.5mm2 fine stranded or solid conductors and #28AWG to #14AWG fine stranded or solid conductors. The terminal block is made from polyamide (PA) 66 and halogen-free materials, supports 2-wires (1 clamp + 1 clamp) connections, and has a diameter rating of 500 V according to IEC standards.
