722-736 WAGO Industrial Automation Components
Part#:722-736
Manufacturer:WAGO
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
722-736 WAGO - THT female header; straight; Pin spacing 7.5 mm; 6-pole; 100% protected against mismating; 0.6 x 1.0 mm solder pin; light gray
Product Details
- Weight 6.610001738 g
- Country Of Origin Germany
- HTS Code 85366990990
- Contact Type Tin
- Width 1.732 inches, 44 millimeters
- Depth 0.457 inches, 11.6 millimeters
- Current 12 amperes, 15 amperes
- Insulation Material Polyamide
- Flammability Class V0
- Connection Type For PCB
- Package Type Box
- Contact Material Copper Alloy
- Weight 6.610 grams
- Height 0.915 inches, 23.25 millimeters
- Country of Origin Germany
- Color Gray
- Voltage 300 volts, 500 volts
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 722-736 on Powermatic Associates is $5.06. Order now.
About the product
WAGO 722-736 is a connector part of the MCS - MULTI CONNECTION SYSTEM, designed without breaking capacity as per DIN EN 61984, indicating it should not be connected or disconnected under load or when live. It adheres to IEC/EN 60664-1 standards, with nominal voltages of 500V (III/3), 630V (III/2), and 1000V (II/2), all with a rated impulse voltage of 6kV and a rated current of 12A. UL and CSA approvals include ratings of 300V and 600V with currents up to 15A, depending on the use group. This connector features a total of 6 potentials, a single connection type across one level, and a 6 pole number for connection 1. Its physical specifications include a pin spacing of 7.5mm, dimensions of 44mm in width, 23.25mm in height, and a depth of 11.6mm, with a solder pin length of 5mm. It offers variable coding, anti-rotation protection, and mismating protection but lacks a locking mechanism for the plug-in connection. The connector is designed for PCB with a 90° mating direction, THT PCB contact, and tin-plated copper alloy contacts. The insulation material is Polyamide (PA66) in light gray, meeting the UL94 V0 flammability class. It operates within a temperature range of -60 to +85°C and weighs 6.6g. This product is RoHS compliant, packaged in boxes of 50 units, and has a GTIN of 4044918580922.
