804-112 WAGO Industrial Automation Components
Part#:804-112
Manufacturer:WAGO
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
804-112 WAGO - PCB terminal block; push-button; 2.5 mm²; Pin spacing 5 mm; 12-pole; Push-in CAGE CLAMP®; 2,50 mm²; gray
Product Details
- Weight 12.04800317 g
- Country Of Origin Switzerland
- HTS Code 85369010000
- Depth 0.531 inches, 15 millimeters
- Contact Type Tin
- Voltage 250 volts, 300 volts
- Color Gray
- Package Type Box
- Actuator Push-button
- Insulation Material Polyamide
- Flammability Class V0
- Width 2.421 inches, 61.5 millimeters
- Current 10 amperes, 24 amperes
- Contact Material Copper
- Weight 12.048 grams
- Height 0.713 inches, 18.1 millimeters
- Conductor Size 12 american wire gauge, 2.5 millimeters
- Strip Length 0.43 inches, 11 millimeters
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 804-112 on Powermatic Associates is $6.43. Order now.
About the product
WAGO 804-112 is an automation part with a short circuit breaking rating as per IEC/EN 60664-1. It features nominal voltages of 250V (III/3), 320V (III/2), and 630V (II/2), with rated impulse voltages of 4kV for all categories. The rated current is 24A, and it has a rated surge voltage of 4kV (II/2). UL and CSA approvals include a rated voltage of 300V and a rated current of 10A for both Use Group B and D. This part has 12 connection points, supports a single connection type with one level, and utilizes Push-in CAGE CLAMP technology with push-button actuation. It accommodates solid and fine-stranded conductors ranging from 0.25 to 2.5mm2 (20 to 12 AWG), with specific allowances for insulated and uninsulated ferrules. The strip length for connections is 10 to 11mm, and the conductor connection direction to PCB is 0°. It features a 12 pole number, 5mm pin spacing, and dimensions of 61.5mm in width, 18.1mm in height, 15mm in depth, with a height from the surface of 14.5mm. The solder pin length is 3.6mm, with dimensions of 0.8 x 0.6mm and a drilled hole diameter of 1.1 (+0.1)mm. The terminal strip supports THT PCB contact with a staggered solder pin arrangement and two solder pins per potential. It is gray, made from Polyamide (PA66) with a V0 flammability class, and uses Chrome-Nickel spring steel and Electrolytic Copper with tin plating for the clamping spring and contact materials, respectively. The part weighs 12g, has a fire load of 0.262MJ, and operates within a temperature range of -60 to +105°C. It is RoHS compliant without exemption, packaged in boxes of 80 (20 pcs per SPU), and has a GTIN of 4044918515245 with a customs tariff number of 85369010000.
