805-114 WAGO Terminal Blocks

WAGO 805-114 is an automation part with a short circuit breaking rating as per IEC/EN 60664-1, featuring nominal voltages of 250V (III/3), 320V (III/2), and 630V (II/2) with a rated impulse voltage of 4kV across these categories. It has a rated current of 17.5A according to IEC/EN standards and complies with UL 1059, having rated voltages and currents under UL as 300V/10A (Use Group B), 150V/10A (Use Group C), and 300V/10A (Use Group D). This part includes 14 connection points, all utilizing Push-in CAGE CLAMP technology with push-button actuation. It supports solid and fine-stranded conductors ranging from 0.2 to 1.5mm2 (24 to 16 AWG), with strip length specifications of 9 to 10mm. The physical dimensions include a width of 50.5mm, height of 13.7mm, and depth of 13.6mm, with a pin spacing of 3.5mm. It is designed for PCB contact through THT with a single solder pin per potential, made from Polyamide (PA66) in gray, featuring a flammability class of UL94 V0. The clamping spring is made from Chrome-Nickel spring steel (CrNi), and the contact material is Electrolytic Copper (ECu) with tin plating. It operates within a temperature range of -60 to +105°C, is RoHS compliant without exemption, and comes in a box packaging of 100 pieces per unit with a country of origin in Poland. The GTIN is 4045454731625, and the customs tariff number is 85369010000.
