832-1105 WAGO Industrial Automation Components

WAGO 832-1105 is a connector part of the MCS - MULTI CONNECTION SYSTEM, designed without breaking capacity as per DIN EN 61984, indicating it should not be connected or disconnected under load or when live. It adheres to IEC/EN 60664-1 standards, with a nominal voltage of 1000V for overvoltage categories III/2 and III/3, and a rated impulse voltage of 8kV. The rated current is 76A according to IEC/EN standards. Under UL 1059 and UL 1977, it has a rated voltage of 600V and rated currents of 66A for Use Group B and C, and 85A under UL 1977. CSA approvals mirror the UL ratings for voltage and current. The connector features 5 connection points, supports a single connection type across one level, and utilizes Push-in CAGE CLAMP technology with lever actuation. It accommodates solid and fine-stranded conductors ranging from 0.75 to 25mm2 (18 to 4 AWG), with specific strip length requirements. The part has a 5-pole configuration, with a 0° conductor entry direction to mating direction, and a pin spacing of 10.16mm. Its dimensions are 52.1mm in width, 29.1mm in height, and 49.8mm in depth. It includes variable coding, anti-rotation protection, and is designed as a female connector/socket for conductor connection without mismating protection. The connector is made from light gray Polybutylene terephthalate (PBT) with a V0 flammability class, and features chrome-nickel spring steel for the clamping and additional spring material, with electrolytic copper contacts plated in silver. It has a fire load of 1.14MJ and weighs 66.8g. The operational temperature range is -60 to +120°C, with a processing temperature range of -35 to +60°C. It is RoHS compliant, packaged in boxes of 20 pieces, and manufactured in Germany with a GTIN of 4055143736749 and a customs tariff number of 85366990990.
