.1618OS1ASPRBO48Z-S WEG AC Motors
Product Details
- Number of Poles 4 Pole
- Voltage 115 V
- Output Rating 0.16 HP
- Rated Speed 1725 rpm
- Flange Type Without
- Rated voltage 115 V
- Insulation Class F
- Temperature rise 80 K
- Synchronous speed 1800 rpm
- Rated current 3.04 A
- Rated torque 0.487 ft.lb
- Altitude 1000 m.a.s.l.
- Output 0.16 HP (0.12 kW)
- Locked rotor torque 130 %
- Duty Cycle Cont.(S1)
- Number of poles 4
- L. R. Amperes 18.8 A
- Mounting F-1
- Standard NEMA MG-1
- Rated speed 1725 rpm
- LRC 6.2x(Code P)
- Ambient temperature -20°C to +40°C
- Frequency 60 Hz
- No load current 2.80 A
- Rotation¹ Both (CW and CCW)
- Locked rotor time 10s (cold) 6s (hot)
- Terminal box¹ Without Terminal Box
- Number of Poles 4
- Design N
- Enclosure IC01 - ODP
- Output rating 0.16 HP
- Slip 4.17 %
- Service factor 1.35
- Starting Method Direct On Line
- Voltage 115 V
- Frame 48Z
- Breakdown torque 270 %
- Approx. weight³ 15.9 lb
- Flange Without
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
