.5018OT1BRBOW56-S WEG AC Motors
Product Details
- Number of Poles 4 Pole
- Voltage 115/208-230 V
- Output Rating 0.5 HP
- Rated Speed 1730 rpm
- Flange Type Without
- Output 0.5 HP (0.37 kW)
- Rated torque 1.52 ft.lb
- Duty Cycle Cont.(S1)
- Voltage 115/208-230 V
- Number of Poles 4
- Breakdown torque 270 %
- Mounting F-1
- Rated speed 1730 rpm
- Rated voltage 115/208-230 V
- Design N
- Enclosure IC01 - ODP
- Rotation¹ Both (CW and CCW)
- Synchronous speed 1800 rpm
- LRC 7.7x(Code K)
- No load current 2.70/1.16-1.35 A
- Insulation Class F
- Starting Method Direct On Line
- Output rating 0.5 HP
- Terminal box¹ Without Terminal Box
- Frame W56
- L. R. Amperes 37.4/23.4-18.7 A
- Service factor 1.25 (1.00 @ 208V)
- Approx. weight³ 25.8 lb
- Noise level² 50.0 dB(A)
- Rated current 4.86/3.04-2.43 A
- Locked rotor time 27s (cold) 15s (hot)
- Ambient temperature -20°C to +40°C
- Standard NEMA MG-1
- Slip 3.89 %
- Moment of inertia (J) 0.0520 sq.ft.lb
- Altitude 1000 m.a.s.l.
- Flange Without
- Frequency 60 Hz
- Locked rotor torque 300 %
- Temperature rise 80 K
- Number of poles 4
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
