.7518ES3E56-S WEG AC Motors
Product Details
- Number of Poles 4 Pole
- Voltage 208-230/460 V
- Output Rating 0.75 HP
- Rated Speed 1755 rpm
- Flange Type Without
- Frame 56
- No load current 1.55-1.80/0.900 A
- Approx. weight³ 23.7 lb
- Terminal box¹ Left position
- Rated current 2.70-2.44/1.22 A
- Insulation Class F
- Locked rotor time 30s (cold) 17s (hot)
- Standard NEMA MG-1
- Number of Poles 4
- Service factor 1.15 (1.00 @ 208V)
- Voltage 208-230/460//190-220/380-415 V
- L. R. Amperes 18.6-16.8/8.42 A
- Moment of inertia (J) 0.0648 sq.ft.lb
- Output rating 0.75 HP
- Frequency 60 Hz
- Temperature rise 80 K
- Noise level² 52.0 dB(A)
- Number of poles 4
- Output 0.75 HP (0.55 kW)
- Locked rotor torque 240 %
- Enclosure IC411 - TEFC
- Synchronous speed 1800 rpm
- Rated speed 1755 rpm
- LRC 6.9x(Code K)
- Duty Cycle Cont.(S1)
- Degree of Protection IP55
- Rated voltage 208-230/460 V
- Starting Method Direct On Line
- Altitude 1000 m.a.s.l.
- Flange Without
- Breakdown torque 300 %
- Rotation¹ Both (CW and CCW)
- Slip 2.50 %
- Rated torque 2.24 ft.lb
- Ambient temperature -20°C to +40°C
- Mounting F-1
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
