00118OT3P143T-S WEG AC Motors
Product Details
- Number of Poles 4 Pole
- Voltage 200 V
- Output Rating 1 HP
- Rated Speed 1760 rpm
- Flange Type Without
- L. R. Amperes 27.8 A
- Service factor 1.15
- Approx. weight³ 34.5 lb
- Terminal box¹ Left position
- Slip 2.22 %
- Insulation Class F
- Noise level² 52.0 dB(A)
- Output rating 1 HP
- Rated voltage 200 V
- Moment of inertia (J) 0.1101 sq.ft.lb
- Rotation¹ Both (CW and CCW)
- Number of Poles 4
- Rated torque 2.98 ft.lb
- Duty Cycle Cont.(S1)
- Synchronous speed 1800 rpm
- Rated current 3.47 A
- Design B
- Standard NEMA MG-1
- Output 1 HP (0.75 kW)
- Breakdown torque 360 %
- Starting Method Direct On Line
- Voltage 200 V
- Frequency 60 Hz
- No load current 2.20 A
- Mounting F-1
- Number of poles 4
- Rated speed 1760 rpm
- Locked rotor torque 290 %
- Enclosure IC01 - ODP
- LRC 8.0x(Code L)
- Temperature rise 80 K
- Ambient temperature -20°C to +40°C
- Frame 143/5T
- Locked rotor time 39s (cold) 22s (hot)
- Altitude 1000 m.a.s.l.
- Flange Without
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
