00218ES1E145T-S WEG AC Motors
Product Details
- Number of Poles 4 Pole
- Voltage 208-230/460 V
- Output Rating 2 HP
- Rated Speed 1745 rpm
- Flange Type Without
- Rated voltage 208-230/460 V
- Locked rotor time 10s (cold) 6s (hot)
- Mounting F-1
- Terminal box¹ Left position
- Rated speed 1745 rpm
- Insulation Class F
- Voltage 208-230/460 V
- Frequency 60 Hz
- Design L
- Noise level² 54.0 dB(A)
- Rated current 11.1-10.0/5.00 A
- Temperature rise 80 K
- Duty Cycle Cont.(S1)
- Standard NEMA MG-1
- Number of Poles 4
- No load current 4.66-5.40/2.70 A
- Enclosure IC411 - TEFC
- Output rating 2 HP
- Output 2 HP (1.5 kW)
- Rated torque 6.02 ft.lb
- Service factor 1.15 (1.00 @ 208V)
- Rotation¹ Both (CW and CCW)
- L. R. Amperes 88.8-80.0/40.0 A
- Locked rotor torque 260 %
- Degree of Protection IP55
- Number of poles 4
- Frame 143/5T
- Moment of inertia (J) 0.1614 sq.ft.lb
- Starting Method Direct On Line
- Synchronous speed 1800 rpm
- Slip 3.06 %
- Breakdown torque 260 %
- Ambient temperature -20°C to +40°C
- Flange Without
- LRC 8.0x(Code L)
- Altitude 1000 m.a.s.l.
- Approx. weight³ 53.3 lb
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
