00336OT1B56C-S WEG AC Motors

Product Details

• Number of Poles
  2 Pole
• Voltage
  115/208-230 V
• Output Rating
  3 HP
• Rated Speed
  3500 rpm
• Flange Type
  C
• Rated speed
  3500 rpm
• Rated torque
  4.50 ft.lb
• Noise level²
  58.0 dB(A)
• Frame
  56HC
• Locked rotor torque
  220 %
• Duty Cycle
  Cont.(S1)
• Voltage
  115/208-230 V
• Rated voltage
  115/208-230 V
• No load current
  7.80/3.36-3.90 A
• Ambient temperature
  -20°C to +40°C
• Terminal box¹
  Without Terminal Box
• Slip
  2.78 %
• Insulation Class
  F
• Mounting
  F-1
• Synchronous speed
  3600 rpm
Rated current
24.4/13.5-12.2 A
Locked rotor time
10s (cold) 6s (hot)
Service factor
1.15 (1.00 @ 208V)
Standard
NEMA MG-1
Number of Poles
2
Design
L
Enclosure
IC01 - ODP
L. R. Amperes
200/111-100 A
Breakdown torque
280 %
Altitude
1000 m.a.s.l.
Flange
C
Output
3 HP (2.2 kW)
Temperature rise
80 K
Approx. weight³
47.2 lb
LRC
8.2x(Code J)
Starting Method
Direct On Line
Output rating
3 HP
Frequency
60 Hz
Moment of inertia (J)
0.0944 sq.ft.lb
Rotation¹
Both (CW and CCW)
Number of poles
2
