00536OT3E182TC-S WEG AC Motors
Product Details
- Number of Poles 2 Pole
- Voltage 230/460 V
- Output Rating 5 HP
- Rated Speed 3510 rpm
- Flange Type C
- Number of Poles 2
- Slip 2.50 %
- L. R. Amperes 96.1/48.0 A
- Duty Cycle Cont.(S1)
- Approx. weight³ 68.9 lb
- Rated voltage 230/460 V
- Rated torque 7.48 ft.lb
- Temperature rise 80 K
- Terminal box¹ Left position
- Frequency 60 Hz
- Altitude 1000 m.a.s.l.
- Rotation¹ Both (CW and CCW)
- Rated current 12.6/6.32 A
- Starting Method Direct On Line
- Noise level² 65.0 dB(A)
- No load current 6.20/3.10 A
- Ambient temperature -20°C to +40°C
- Number of poles 2
- Output 5 HP (3.7 kW)
- Moment of inertia (J) 0.1386 sq.ft.lb
- Standard NEMA MG-1
- Rated speed 3510 rpm
- Breakdown torque 300 %
- Enclosure IC01 - ODP
- Flange C
- Frame 182/4TC
- Locked rotor torque 190 %
- Design B
- Voltage 230/460//190-220/380-415 V
- LRC 7.6x(Code J)
- Locked rotor time 27s (cold) 15s (hot)
- Synchronous speed 3600 rpm
- Insulation Class F
- Mounting F-1
- Output rating 5 HP
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
