02018EP3ER256TC-S WEG AC Motors
Product Details
- Number of Poles 4 Pole
- Voltage 230/460 V
- Output Rating 20 HP
- Rated Speed 1760 rpm
- Flange Type C
- Rated voltage 230/460 V
- Breakdown torque 270 %
- Degree of Protection IP55
- Terminal box¹ Left position
- Rated current 49.8/24.9 A
- Rated speed 1760 rpm
- Moment of inertia (J) 2.15 sq.ft.lb
- Temperature rise 80 K
- Standard NEMA MG-1
- Frequency 60 Hz
- Slip 2.22 %
- Rated torque 59.7 ft.lb
- No load current 21.6/10.8 A
- Starting Method Direct On Line
- Rotation¹ Both (CW and CCW)
- Synchronous speed 1800 rpm
- LRC 5.9x(Code G)
- Number of Poles 4
- Insulation Class F
- Mounting F-1
- Frame 254/6TC
- Design B
- Voltage 230/460//190-220/380-415 V
- Output 20 HP (15 kW)
- Locked rotor torque 210 %
- Altitude 1000 m.a.s.l.
- Approx. weight³ 216 lb
- L. R. Amperes 294/147 A
- Locked rotor time 21s (cold) 12s (hot)
- Enclosure IC411 - TEFC
- Output rating 20 HP
- Duty Cycle Cont.(S1)
- Noise level² 68.0 dB(A)
- Ambient temperature -20°C to +40°C
- Number of poles 4
- Flange C
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
