02036OT3H254T-S WEG AC Motors
Product Details
- Number of Poles 2 Pole
- Voltage 575 V
- Output Rating 20 HP
- Rated Speed 3525 rpm
- Flange Type Without
- Rated current 19.0 A
- Breakdown torque 240 %
- Temperature rise 80 K
- Standard NEMA MG-1
- L. R. Amperes 114 A
- Insulation Class F
- Approx. weight³ 168 lb
- LRC 6.0x(Code G)
- Duty Cycle Cont.(S1)
- Synchronous speed 3600 rpm
- Frame 254/6T
- No load current 6.80 A
- Starting Method Direct On Line
- Number of poles 2
- Number of Poles 2
- Locked rotor time 23s (cold) 13s (hot)
- Noise level² 70.0 dB(A)
- Terminal box¹ Left position
- Frequency 60 Hz
- Moment of inertia (J) 0.7848 sq.ft.lb
- Altitude 1000 m.a.s.l.
- Output rating 20 HP
- Output 20 HP (15 kW)
- Locked rotor torque 180 %
- Mounting F-1
- Rated speed 3525 rpm
- Design B
- Rotation¹ Both (CW and CCW)
- Flange Without
- Rated voltage 575 V
- Ambient temperature -20°C to +40°C
- Voltage 575 V
- Slip 2.08 %
- Rated torque 29.8 ft.lb
- Service factor 1.15
- Enclosure IC01 - ODP
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
