05012ET3E365T-W22 WEG AC Motors

Product Details

• Number of Poles
  6 Pole
• Voltage
  230/460 V
• Output Rating
  50 HP
• Rated Speed
  1183 rpm
• Flange Type
  Without
• Slip
  1.42 %
• Rated torque
  222 ft.lb
• Ambient temperature
  -20°C to +40°C
• L. R. Amperes
  735/367 A
• Rated speed
  1183 rpm
• Moment of inertia (J)
  32.4 sq.ft.lb
• Locked rotor torque
  200 %
• Mounting
  F-1
• Enclosure
  IC411 - TEFC
• LRC
  6.4x(Code G)
• Temperature rise
  80 K
• Rated current
  115/57.4 A
• Locked rotor time
  32s (cold) 18s (hot)
• Altitude
  1000 m.a.s.l.
• Frequency
  60 Hz
Insulation Class
F
Breakdown torque
240 %
Voltage
230/460//380 V
Rated voltage
230/460 V
Design
B
Degree of Protection
IP55
Output rating
50 HP
Number of Poles
6
Service factor
1.25
Rotation¹
Both (CW and CCW)
Frame
364/5T
No load current
40.0/20.0 A
Starting Method
Direct On Line
Noise level²
66.0 dB(A)
Terminal box¹
Left position
Output
50 HP (37 kW)
Duty Cycle
Cont.(S1)
Standard
NEMA MG-1
Approx. weight³
905 lb
Synchronous speed
1200 rpm
Flange
Without
Number of poles
6
