05036EG3E326TS-W22 WEG AC Motors

Product Details

• Number of Poles
  2 Pole
• Voltage
  230/460 V
• Output Rating
  50 HP
• Rated Speed
  3570 rpm
• Flange Type
  Without
• Slip
  0.83 %
• Breakdown torque
  330 %
• Number of poles
  2
• Mounting
  F-1
• L. R. Amperes
  948/474 A
• Service factor
  1.25
• Approx. weight³
  600 lb
• Frequency
  60 Hz
• No load current
  39.0/19.5 A
• Temperature rise
  80 K
• Noise level²
  76.0 dB(A)
• Rated current
  114/57.1 A
• Rated torque
  73.5 ft.lb
• Enclosure
  IC411 - TEFC
• Number of Poles
  2
Output
50 HP (37 kW)
Moment of inertia (J)
5.43 sq.ft.lb
Locked rotor time
45s (cold) 25s (hot)
Altitude
1000 m.a.s.l.
Rotation¹
Both (CW and CCW)
Flange
Without
Rated speed
3570 rpm
Design
A
Ambient temperature
-20°C to +40°C
Standard
NEMA MG-1
LRC
8.3x(Code J)
Starting Method
Direct On Line
Output rating
50 HP
Frame
324/6TS
Locked rotor torque
330 %
Degree of Protection
IP55
Synchronous speed
3600 rpm
Rated voltage
230/460 V
Insulation Class
F
Duty Cycle
Cont.(S1)
Voltage
208-230/460//380 V
Terminal box¹
Left position
