06012OT3E404T-W40 WEG AC Motors
Product Details
- Number of Poles 6 Pole
- Voltage 230/460 V
- Output Rating 60 HP
- Rated Speed 1185 rpm
- Flange Type Without
- Rated speed 1185 rpm
- Moment of inertia (J) 29.4 sq.ft.lb
- Enclosure IC01 - ODP
- Flange Without
- LRC 6.7x(Code G)
- Temperature rise 80 K
- Approx. weight³ 967 lb
- Terminal box¹ Left position
- Frame 404/5T
- Locked rotor torque 240 %
- Degree of Protection IP23
- Number of poles 6
- Number of Poles 6
- Locked rotor time 28s (cold) 16s (hot)
- Ambient temperature -20°C to +40°C
- Standard NEMA MG-1
- Output 60 HP (45 kW)
- Breakdown torque 250 %
- Duty Cycle Cont.(S1)
- Output rating 60 HP
- Frequency 60 Hz
- Rated torque 266 ft.lb
- Altitude 1000 m.a.s.l.
- Synchronous speed 1200 rpm
- Rated current 141/70.3 A
- Service factor 1.25
- Rotation¹ Both (CW and CCW)
- Rated voltage 230/460 V
- Design B
- Mounting F-1
- L. R. Amperes 942/471 A
- Starting Method Direct On Line
- Voltage 230/460//380 V
- Slip 1.25 %
- No load current 50.0/25.0 A
- Insulation Class F
- Noise level² 68.0 dB(A)
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
