15036OT3G405TS-RFW40 WEG AC Motors
Product Details
- Number of Poles 2 Pole
- Voltage 460 V
- Output Rating 150 HP
- Rated Speed 3552 rpm
- Flange Type Without
- Slip 1.33 %
- Locked rotor torque 200 %
- Locked rotor time 16s (cold) 9s (hot)
- Duty Cycle Cont.(S1)
- Frequency 60 Hz
- Output 150 HP (110 kW)
- Service factor 1.25
- Design B
- Rated current 167 A
- Rated torque 222 ft.lb
- Degree of Protection IP23
- L. R. Amperes 1102 A
- Rated voltage 460 V
- Moment of inertia (J) 8.80 sq.ft.lb
- Approx. weight³ 931 lb
- Frame 404/5TS
- Insulation Class F
- Ambient temperature -20°C to +40°C
- Flange Without
- Rated speed 3552 rpm
- Temperature rise 80 K
- No load current 40.0 A
- Voltage 460 V
- Breakdown torque 250 %
- Altitude 1000 m.a.s.l.
- Number of poles 2
- Number of Poles 2
- LRC 6.6x(Code G)
- Starting Method Direct On Line
- Standard NEMA MG-1
- Output rating 150 HP
- Noise level² 84.0 dB(A)
- Rotation¹ Both (CW and CCW)
- Enclosure IC01 - ODP
- Synchronous speed 3600 rpm
- Terminal box¹ Left position
- Mounting F-1
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
