30018ET3GRB449T-W22 WEG AC Motors
Product Details
- Number of Poles 4 Pole
- Voltage 460 V
- Output Rating 300 HP
- Rated Speed 1780 rpm
- Flange Type Without
- LRC 6.5x(Code G)
- Temperature rise 80 K
- Noise level² 75.0 dB(A)
- Rated speed 1780 rpm
- Insulation Class F
- Degree of Protection IP55
- Output rating 300 HP
- Slip 1.11 %
- Locked rotor torque 250 %
- Starting Method Direct On Line
- Flange Without
- Output 300 HP (220 kW)
- Locked rotor time 28s (cold) 16s (hot)
- Altitude 1000 m.a.s.l.
- Number of poles 4
- Rated voltage 460 V
- L. R. Amperes 2145 A
- Design B
- Service factor 1.15
- Ambient temperature -20°C to +40°C
- Standard NEMA MG-1
- Synchronous speed 1800 rpm
- Rated current 330 A
- Number of Poles 4
- Moment of inertia (J) 89.6 sq.ft.lb
- Breakdown torque 250 %
- Mounting F-1
- Enclosure IC411 - TEFC
- Voltage 460 V
- No load current 105 A
- Frequency 60 Hz
- Rotation¹ Both (CW and CCW)
- Terminal box¹ Left position
- Frame 447/9T
- Rated torque 885 ft.lb
- Duty Cycle Cont.(S1)
- Approx. weight³ 2885 lb
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
