60018ET3G586/7-W22 WEG AC Motors
Product Details
- Number of Poles 4 Pole
- Voltage 460 V
- Output Rating 600 HP
- Rated Speed 1790 rpm
- Flange Type Without
- LRC 7.1x(Code G)
- Temperature rise 80 K
- Terminal box¹ Left position
- Rated speed 1790 rpm
- Insulation Class F
- Number of poles 4
- Mounting F-1
- Output 600 HP (440 kW)
- Duty Cycle Cont.(S1)
- Voltage 460 V
- L. R. Amperes 4722 A
- Locked rotor torque 229 %
- Noise level² 78.0 dB(A)
- Rated current 665 A
- Moment of inertia (J) 235 sq.ft.lb
- Rotation¹ Both (CW and CCW)
- Number of Poles 4
- Ambient temperature -20°C to +40°C
- Output rating 600 HP
- Frame 586/7T
- Rated torque 1760 ft.lb
- Service factor 1.15
- Flange Without
- Rated voltage 460 V
- No load current 210 A
- Enclosure IC411 - TEFC
- Slip 0.56 %
- Locked rotor time 28s (cold) 16s (hot)
- Frequency 60 Hz
- Breakdown torque 250 %
- Altitude 1000 m.a.s.l.
- Starting Method Direct On Line
- Degree of Protection IP55
- Approx. weight³ 4335 lb
- Standard NEMA MG-1
- Synchronous speed 1800 rpm
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
