K80LGRYPQ Banner Pick-to-Light Sensors

Name: K80LGRYPQ
Brand: Banner
Price: 138 USD
Availability: BackOrder

Part#:K80LGRYPQ

Alt. Part#:77592

Manufacturer:Banner

Category:Pick-to-Light Sensors

Product Lifecycle:Active

Product description

K80 Series EZ-LIGHT: 3-Color General Purpose Indicator; Voltage: 18-30 V dc; Housing: Polycarbonate; IP67; Input: PNP; Colors: Green Red Yellow; M12 Integral QD

Product Details

Weight
317.5144 g
Country Of Origin
US
Min Op. Temperature (°C)
-40
Modbus RTU
No
Color Input Control
Individual (One wire/color, same number of colors as input wires)
Color Option 2
Red
Environmental Rating
IP67
Pro-Editor Compatible (Discrete)
No
Number of Colors / Segments
3
Max Input Response Time (ms)
10
Physical Dimensions (LxWxH or DxH mm)
107.6 x 80.9 x 66.7
Indication
Yes
Animation Option 1
Solid On
Number of Input Pins/Conductors
5
Feature: Quick Disconnect
Yes
Power Source
DC
Connection
Integral QD
Feature: Hazardous Area
No
Multi-Color Device
Single Color On
Mounting Thread
No Thread

Product Size (mm)

Color Option 3

Yellow

Primary Housing Color

Yellow

Housing Style

Flat Mount - Dome Window

Color Technology

Standard LED

Feature: Audible

IO Link

Cable Length (m)

0.15

Color Option 1

Green

Supply Voltage

18-30 V dc

Feature: Chemical Resistant

Power

Max Current Color (mA)

Primary Window Material

Acrylic Diffused

Primary Housing Material

Polycarbonate

Quick Disconnect Type

M12 (Euro)

Input Type

PNP

Max Op. Temperature (°C)

Wireless

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of K80LGRYPQ on Powermatic Associates is $138.00. Order now.

About the product

Banner Engineering K80LGRYPQ is a flat-pack LED pilot light indicator from the EZ-LIGHT series, featuring a 3-color G/R/Y color pattern LED illumination. It comes in a yellow housing with a dome window on a flat-pack body, constructed from an acrylic diffused window and a polycarbonate (PC) base. This part offers a screw-clamp terminal connection and operates on a supply voltage of 18Vdc to 30Vdc, with a nominal voltage of 24Vdc. It is designed for surface or wall mounting with dimensions of 80x80mm and has a 50mm / 2" dome diameter. The K80LGRYPQ can operate in ambient air temperatures ranging from -40°C to +50°C and is rated with a degree of protection of IP67. It has a current consumption of 40mA and includes 3 digital inputs (18-30Vdc; PNP) for color control.
