M18-4VNFF200-Q8 Banner Proximity Sensors

Name: M18-4VNFF200-Q8
Brand: Banner
Price: 139 USD
Availability: BackOrder

M18-4VNFF200-Q8 on Powermatic Associates

Part#:M18-4VNFF200-Q8

Alt. Part#:800610

Manufacturer:Banner

Category:Proximity Sensors

Product Lifecycle:Active

Product description

M18-4 Series: Stainless: Fixed Field; Range: 200 mm; Input 10-30 V dc; Outputs: Complementary NPN; 4-pin M12 Integral QD

Product Details

Weight
50.9837408 g
Country Of Origin
CN
Main function
Sensor (Photo-electric)
Design
background / foreground suppression system
Wavelength
624 nm
Response time
1.5ms / 0.0015 s
Primary brand
Banner Engineering
Supply voltage (DC)
10Vdc-30Vdc (12Vdc / 24Vdc nom.)
Shape
Cylindrical threaded/barrel
Light Color
Visible red
Sensing distance
200mm
Degree of protection
IP67 IP69K
Operating mode
Light-ON Dark-ON
Digital outputs
1 x digital output (NPN transistor)
Order code / Manufacturer SKU
800610
Equivalent to
M184VNFF200Q8
Functions
Fixed-field photo-electric sensor green LED (power ON) 2 x yellow LED (output conducting)
Material
Stainless steel housing Acrylic lns.
Product series / family name
M18 barrel series
Ambient air temperature for operation
-40...+70 °C

Sub-range name

M18-3 (stainless steel)

Thread size

M18

Compliant with standard(s)

cULus CE

Connection type

Pre-equipped with 4-pin Euro-style M12 connector

Input/Output

Discrete

Min Op. Temp. (°C)

-40

IP Rating

IP67, IP69

Feature: Washdown Rated

Yes

Power

Power Supply/Supply Voltage

10-30 V dc

Special Feature: Water Detection

Lens Material

Acrylic

Sensing Mode (General)

Proximity

Outputs

NPN

Special Feature: Remote Teach

Max Op. Relative Humidity [%]

95% @ 50°C

Sensing Beam

Visible Red LED

Connection

Integral QD

Output response time (ms)

1.5

Number of Pins

Feature: Audible

Small Visible Spot

LED

Special Feature: Intrinsically Safe

Adjustments

N/A

Feature: Encapsulated

Housing Style

Barrel

Operation

Light/Dark Operate

NEMA Rating

N/A

Feature: Ecolab Certified

Yes

Max Sensing Distance (mm)

200

Sensing Beam Wavelength

624

Barrel Diameter (mm)

DeviceNet

Primary Housing Material

Stainless Steel

Max Op. Temp. (°C)

Repeatability (µs)

100

Feature: Timing (Hold/Delay)

Indicator

LEDs

Feature: Health/ Marginal Signal Output

Yes

Sensing Mode (Detailed)

Background Suppression (Fixed)

Delay at Power-up (ms)

100

Quick Disconnect Type

M12 (Euro)

Opposed Mode Emitter/Receiver

N/A

Feature: Hazardous Area

Feature: Chemical Resistant

Yes

IO Link

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of M18-4VNFF200-Q8 on Powermatic Associates is $139.00. Order now.

About the product

Banner Engineering M18-4VNFF200-Q8 is a fixed-field photo-electric sensor from the M18-3 (stainless steel) series, designed with a background/foreground suppression system. It features a visible red light with a wavelength of 624 nm and is housed in a stainless steel casing with an acrylic lens. This sensor is shaped in an M18 cylindrical threaded/barrel form and comes pre-equipped with a 4-pin Euro-style M12 connector for connectivity. It operates on a supply voltage range of 10Vdc to 30Vdc, with nominal values of 12Vdc and 24Vdc. The M18-4VNFF200-Q8 can function within an ambient air temperature range of -40 to +70 degrees Celsius and offers a degree of protection rated at IP67 and IP69K. It supports both Light-ON and Dark-ON operating modes, has a thread size of M18, and provides a sensing distance of 200mm. Additionally, it features 1 x digital output (NPN transistor; complementary NO/NC) with a response time of 1.5ms / 0.0015 s.
