VS8EAPRQ Banner Proximity Sensors
Part#:VS8EAPRQ
Alt. Part#:803486
Manufacturer:Banner
Category:Proximity Sensors
Product Lifecycle:Active
Jun 28, 2025
Product description
VS8 Series: Laser Receiver; Range: 3 m; Input: 10-30 V dc; Output: PNP; 200 mm 4-pin M8 Pigtail QD
Product Details
- Weight 10.3418976 g
- Country Of Origin DE
- Supply voltage (DC) 10Vdc-30Vdc (12Vdc / 24Vdc nom.)
- Light Color Visible red
- Response time 0.5ms / 0.0005 s
- Ambient air temperature for operation -20...+60 °C
- Main function Sensor (Photo-electric)
- Sensing distance 3m
- Material thermoplastic housing PMMA lns. PUR (cable)
- Order code / Manufacturer SKU 803486
- Functions Photo-electric sensor receiver green LED (power ON) yellow LED (output state) TEACH mode
- Shape Rectangular
- Digital outputs 1 x digital output (PNP transistor)
- Primary brand Banner Engineering
- Design through-beam system / opposed mode
- Connection type Pre-wired with 7.5" / 20cm pigtail terminated with 4-pin Pico-style M8 connector
- Compliant with standard(s) cULus CE
- Sub-range name VS8 series
- Wavelength 650 nm
- Degree of protection IP67
- Operating mode Light-ON Dark-ON
- Outputs PNP
- Sensing Mode (Detailed) Receiver
- Power Supply/Supply Voltage 10-30 V dc
- Special Feature: Intrinsically Safe No
- Number of Pins 4
- Adjustments Teach Button
- IO Link No
- Quick Disconnect Type M8 (Pico)
- Repeatability (µs) N/A
- Feature: Timing (Hold/Delay) No
- Input/Output Discrete
- Connection Pigtail QD
- NEMA Rating N/A
- DeviceNet No
- Sensing Beam Visible Red LED
- Max Sensing Distance (mm) 3000
- Output response time (ms) 0.5
- Indicator LEDs
- Feature: Audible No
- Primary Housing Material PUR
- Special Feature: Remote Teach Yes
- Barrel Diameter (mm) N/A
- Feature: Hazardous Area No
- Min Op. Temp. (°C) -20
- Sensing Beam Wavelength 650
- Lens Material PMMA
- Feature: Chemical Resistant No
- Housing Style Rectangular
- Max Op. Temp. (°C) 60
- IP Rating IP67
- Opposed Mode Emitter/Receiver Receiver
- Sensing Mode (General) Opposed
- Operation Light/Dark Operate
- Delay at Power-up (ms) 300
- Feature: Encapsulated No
- Power DC
- Special Feature: Water Detection No
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of VS8EAPRQ on Powermatic Associates is $183.00. Order now.
About the product
Banner Engineering VS8EAPRQ is a photo-electric sensor designed with a thermoplastic housing and a polymethyl methacrylate (PMMA) lens, featuring a polyurethane (PUR) cable for connectivity. This sensor offers a degree of protection rated at IP67, making it suitable for operation in environments with ambient air temperatures ranging from -20 to +60 °C. It operates in both Light-ON and Dark-ON modes and includes a single digital output (PNP transistor) with a rapid response time of 0.5ms / 0.0005 s. The VS8EAPRQ is equipped with a pre-wired 7.5" / 20cm pigtail that terminates with a 4-pin Pico-style M8 connector, ensuring easy installation. Its rectangular shape and visible red light, with a wavelength of 650 nm, are designed for through-beam system applications in the opposed mode TEACH mode. This sensor supports a supply voltage range of 10Vdc-30Vdc (12Vdc / 24Vdc nom.) and is capable of sensing distances up to 3m. It is part of the VS8 series, specifically functioning as a photo-electric sensor (receiver alone).
