S30SN6LP Banner Proximity Sensors

S30SN6LP on Powermatic Associates
Banner

Part#:S30SN6LP

Alt. Part#:32326

Manufacturer:Banner

Category:Proximity Sensors

Product Lifecycle:Active

Product description

EZ-BEAM S30 Series: Polarized Retro; Range: 6 m; Input: 10-30 V dc; Output: Complementary NPN; 2 m (6.5 ft) Cable

Product Details

  • Weight
    187.333496 g
  • Country Of Origin
    MX
  • Min Op. Temp. (°C)
    -40
  • Output response time (ms)
    3
  • Operation
    Light/Dark Operate
  • DeviceNet
    No
  • IO Link
    No
  • Feature: Health/ Marginal Signal Output
    Yes
  • Feature: Chemical Resistant
    No
  • Feature: Hazardous Area
    No
  • Feature: Audible
    No
  • Feature: Encapsulated
    Yes
  • Opposed Mode Emitter/Receiver
    N/A
  • Feature: Ecolab Certified
    Yes
  • Feature: Timing (Hold/Delay)
    No
  • Indicator
    LEDs
  • Barrel Diameter (mm)
    30
  • Adjustments
    N/A
  • Lens Material
    Acrylic
  • Max Op. Relative Humidity [%]
    90% @ 50°C
  • Repeatability (µs)
    750
  • IP Rating
    IP67
  • NEMA Rating
    NEMA 6P
  • Delay at Power-up (ms)
    100
  • Number of Pins
    4
  • Special Feature: Water Detection
    No
  • Special Feature: Remote Teach
    No
  • Special Feature: Intrinsically Safe
    No
  • Connection
    Cable
  • Max Op. Temp. (°C)
    70
  • Outputs
    NPN
  • Power Supply/Supply Voltage
    10-30 V dc
  • Quick Disconnect Type
    No QD
  • Sensing Beam
    Visible Red LED
  • Housing Style
    Barrel
  • Sensing Mode (Detailed)
    Polarized
  • Max Sensing Distance (mm)
    6000
  • Input/Output
    Discrete
  • Primary Housing Material
    Thermoplastic
  • Sensing Mode (General)
    Retroreflective
  • Power
    DC
  • Cable Length (m)
    2
  • Product series / family name
    EZ-BEAM series
  • Supply voltage (DC)
    10Vdc-30Vdc (12Vdc / 24Vdc nom.)
  • Main function
    Sensor (Photo-electric)
  • Sensing distance
    6m
  • Response time
    3ms / 0.003 s
  • Functions
    Polarized photo-electric sensor green LED (power ON) yellow LED (output state)
  • Operating mode
    Light-ON Dark-ON
  • Compliant with standard(s)
    cULus Listed cCSAus CE
  • Sub-range name
    S30 series
  • Wavelength
    680 nm
  • Digital outputs
    1 x digital output (NPN transistor)
  • Ambient air temperature for operation
    -40...+70 °C
  • Design
    retro-reflective mode
  • Material
    thermoplastic housing
  • Shape
    Cylindrical threaded/barrel
  • Order code / Manufacturer SKU
    32326
  • Degree of protection
    IP69K NEMA 6P
  • Thread size
    M30
  • Primary brand
    Banner Engineering
  • Connection type
    Pre-wired with 6.5ft / 2m cable terminated with bare end flying leads
  • Light Color
    Visible red

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of S30SN6LP on Powermatic Associates is $118.00. Order now.

About the product

Banner Engineering S30SN6LP is a polarized photo-electric sensor from the S30 series, designed in a retro-reflective mode. This sensor features a thermoplastic housing and is pre-wired with a 6.5ft / 2m cable that terminates with bare end flying leads. It operates on a supply voltage range of 10Vdc to 30Vdc, with nominal voltages of 12Vdc and 24Vdc. The S30SN6LP can function within an ambient air temperature range of -40 to +70°C and is rated with a degree of protection IP67 NEMA 6P, making it suitable for various environmental conditions. Its shape is an M30 cylindrical threaded/barrel, and it includes 1 x digital output (NPN transistor; complementary NO/NC) for connectivity. The sensing distance of this sensor is 6m, and it emits a visible red light with a wavelength of 680 nm. It has a quick response time of 3ms / 0.003 s and supports both Light-ON and Dark-ON operating modes.
