SME312DVQDPMA Banner Proximity Sensors
Part#:SME312DVQDPMA
Alt. Part#:72710
Manufacturer:Banner
Category:Proximity Sensors
Product Lifecycle:Active
Product description
SME312DVQDPMA 6 in PUR 5-pin M12 Pigtail
Product Details
- Weight 81.64656 g
- Country Of Origin US
- Sensing Mode (Detailed) Diffuse
- Special Feature: Intrinsically Safe No
- Sensing Mode (General) Proximity
- Power Supply/Supply Voltage 10-30 V dc
- Special Feature: Water Detection No
- Primary Housing Material Thermoplastic
- Special Feature: Remote Teach Yes
- NEMA Rating NEMA 1, 2, 3, 3S, 4, 4X, 6, 12, 13
- Feature: Hazardous Area No
- Power DC
- Min Op. Temp. (°C) -20
- IP Rating IP67
- Indicator LEDs
- Max Sensing Distance (mm) 1100
- Connection Pigtail PUR QD
- Number of Pins 5
- Opposed Mode Emitter/Receiver N/A
- Housing Style Rectangular w/M18 Mount
- Operation Light/Dark Operate
- Sensing Beam Wavelength 650
- Feature: Timing (Hold/Delay) No
- Input/Output Discrete
- Quick Disconnect Type M12 (Euro)
- Lens Material Acrylic
- Feature: Audible No
- Sensing Beam Visible Red LED
- Max Op. Temp. (°C) 70
- Repeatability (µs) 100
- Barrel Diameter (mm) 18
- Feature: Chemical Resistant No
- Outputs Bipolar (NPN & PNP)
- Output response time (ms) 0.5
- Max Op. Relative Humidity [%] 90% @ 50°C
- Delay at Power-up (ms) 1000
- Feature: Encapsulated No
- Adjustments Teach Button
- DeviceNet No
- IO Link No
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of SME312DVQDPMA on Powermatic Associates is $188.00. Order now.
About the product
Banner Engineering SME312DVQDPMA is a photo-electric sensor from the SME312 Expert series, designed with a diffuse mode TEACH mode. This sensor features a thermoplastic housing and an acrylic lens. It comes pre-wired with a 6" / 150mm pigtail terminated with a 5-pin Euro-style M12 connector. The supply voltage required for operation ranges from 10Vdc to 30Vdc, with nominal voltages of 12Vdc and 24Vdc. It is designed for M18 threaded mount installation and can operate within an ambient air temperature range of -20 to +70°C. The SME312DVQDPMA offers a degree of protection rated at IP67, NEMA 1, NEMA 2, NEMA 3, NEMA 3S, NEMA 4, NEMA 4X, NEMA 6, NEMA 12, and NEMA 13. Its rectangular shape incorporates 1 x digital output (PNP/NPN transistor) and has a sensing distance of 1.1m. The sensor emits visible red light with a wavelength of 650 nm and responds in 0.5ms / 0.0005 s, supporting both Light-ON and Dark-ON operating modes.
