VS3RP5XLVQ Banner Proximity Sensors

Product Details

• Weight
  45.3592 g
• Country Of Origin
  MX
• Feature: Chemical Resistant
  No
• IO Link
  No
• DeviceNet
  No
• Feature: Hazardous Area
  No
• Feature: Encapsulated
  No
• Lens Material
  Acrylic
• Opposed Mode Emitter/Receiver
  N/A
• Feature: Timing (Hold/Delay)
  No
• Barrel Diameter (mm)
  N/A
• Feature: Audible
  No
• Adjustments
  N/A
• Indicator
  LEDs
• NEMA Rating
  NEMA 6
• Max Op. Relative Humidity [%]
  80% @ 50°C
• Special Feature: Remote Teach
  No
• Special Feature: Intrinsically Safe
  No
• Special Feature: Water Detection
  No
• Repeatability (µs)
  160
Number of Pins
3
IP Rating
IP67
Output response time (ms)
1
Delay at Power-up (ms)
150
Max Op. Temp. (°C)
55
Min Op. Temp. (°C)
-20
Quick Disconnect Type
M8 (Pico)
Operation
Dark Operate
Connection
Pigtail QD
Power Supply/Supply Voltage
10-30 V dc
Max Sensing Distance (mm)
250
Outputs
PNP
Sensing Beam
Visible Red LED
Power
DC
Primary Housing Material
Thermoplastic
Sensing Mode (Detailed)
Non-Polarized
Sensing Mode (General)
Retroreflective
Housing Style
Rectangular
Input/Output
Discrete
Primary brand
Banner Engineering
Design
retro-reflective mode
Operating mode
Dark-ON NC (Normally Closed)
Material
thermoplastic housing Acrylic lns.
Sensing distance
250mm
Connection type
Pre-wired with 6" / 150mm pigtail terminated with 3-pin Pico-style M8 connector
Order code / Manufacturer SKU
63718
Main function
Sensor (Photo-electric)
Functions
Photo-electric sensor green LED (power ON) yellow LED (light sensed)
Wavelength
680 nm
Response time
(ON) 1ms / 0.001 s(OFF) 0.5ms / 0.0005 s
Ambient air temperature for operation
-20...+55 °C
Sub-range name
VS3 series
Light Color
Visible red
Digital outputs
1 x digital output (PNP transistor)
Supply voltage (DC)
10Vdc-30Vdc (12Vdc / 24Vdc nom.)
Shape
Rectangular
Degree of protection
IP67 NEMA 6
Compliant with standard(s)
CE
