WLB32C285PB Banner Light Bars
Part#:WLB32C285PB
Alt. Part#:87485
Manufacturer:Banner
Category:Light Bars
Product Lifecycle:Active
Product description
WLB32 Work Light Bar; Switched Hi/Low/Off; Length: 285 mm; Voltage: 12-30 V dc; Environmental Rating: IP50; Color: White; Cascadable; 2 m (6.5 ft) Integral Cable; Diffuse window
Product Details
- Weight 317.5144 g
- Country Of Origin MX
- Illumination Yes
- Dimming Option High-Low-Off
- Feature: Hazardous Area No
- Primary Housing Material Aluminum
- Color Option 1 White
- Environmental Rating IP50
- Feature: Cascade Yes
- Number of Colors / Segments 1
- Supply Voltage 12-30 V dc
- Storage Temp (°C) -40 to 70
- IO Link No
- Housing Style Linear Strip
- Color Technology Standard LED
- Illuminated Length (LxWxH mm) 285.0
- Feature: Audible No
- Color Input Control Individual (One wire/color, same number of colors as input wires)
- Lumens Color 1 750
- Illumination Switch Function I=Low; O=OFF; II=High
- Pro-Editor Compatible (Discrete) No
- Product Size (mm) 32
- Color 1 - Wavelength/Color Temp/Coordinates 5000K (Daylight)
- Max Op. Temperature (°C) 70
- Feature: Chemical Resistant No
- Power Source DC
- Connection Cable
- Min Op. Temperature (°C) -40
- Modbus RTU No
- Mounting Thread No Thread
- Number of Input Pins/Conductors 2
- Primary Window Material Polycarbonate Diffused
- Power DC
- Animation Option 1 Solid On
- Physical Dimensions (LxWxH or DxH mm) 313.0 x 31.9 x 46.0
- Wireless No
- Feature: Quick Disconnect No
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of WLB32C285PB on Powermatic Associates is $103.00. Order now.
About the product
Banner Engineering WLB32C285PB is a cascadable industrial LED workstation task light bar designed for a variety of lighting needs. It features a high/low/off switch and provides 1-color Daylight White (DW) LED illumination. The unit operates on a supply voltage range of 12Vdc to 30Vdc, with a nominal voltage of 24Vdc. It measures 285mm in length and 32mm in width. The light bar is constructed with a polycarbonate (PC) diffused window and an aluminium housing, ensuring durability. It comes pre-wired with a 2-meter (approximately 6.5 feet) 2-wire cable terminated with bare end flying leads for easy installation. The linear lighting shape is designed to fit a variety of spaces, and it offers a degree of protection rated at IP50. This task light can operate in ambient air temperatures ranging from -40°C to +70°C. It includes 1 x digital input (12Vdc / 24Vdc) for color control, consumes 800mA of current, and delivers a luminous flux of 750 lumens.
