Eaton

Part#:CHFP

Manufacturer:Eaton

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

CHFP Eaton - Eaton CH 3/4-inch Loadcenter and Breaker Accessories - Filler Plate,Filler plate,CH,0.75 in,Used with CH 3/4 in Loadcenters

Product Details

  • Shipping Length:
    3.00 In.
  • Series:
    CH
  • Shipping Weight:
    0.05
  • UPC:
    782113099026
  • Used On:
    Loadcenter and Circuit Breaker
  • Shipping Width:
    1.00 In.
  • Shipping Height:
    1.00 In.
  • Height
    0.1 inches
  • Amperage
    70 amperes
  • Weight
    .01 pounds
  • Length
    1 inch
  • Bus Material
    Aluminum
  • Interrupt Rating
    10 kiloamps
  • Number of Phases
    3
  • Type
    Filler Plate
  • Size
    3/4 inches

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
