FAZ-C16/3 Eaton Miniature Circuit Breakers (MCBs)

Name: FAZ-C16/3
Brand: Eaton

Part#:FAZ-C16/3

Manufacturer:Eaton

Category:Miniature Circuit Breakers (MCBs)

Product Lifecycle:Active

Product description

FAZ-C16/3 Eaton - UL 1077 Industrial Miniature Circuit Breaker - Supplementary Protector

Product Details

Number of Poles
3 Pole
Current Rating
16 A
Trip Curve
C
SCCR
10 kA
UL Standard
1077
UL CCN
QVNU2
UL File No.
E177451
Terminal Type
Compression
EAN
4015082788735
Terminals
Standard
Product Height
2.07 in
Frequency rating
50-60 Hz
Product Length/Depth
2.07 in
Amperage Rating
16 A
Product Width
2 in
Circuit protection
C curve
Certifications
CSA Std. C22.2 No.235 UL 1077 IEC 60947-2
Trip Type
5-10X /n
Catalog Notes
Positioned for medium inrush startup currents to provide protection for small transformers and pilot devices.
Number of poles
Three-pole

Product Name

Eaton FAZ supplementary protector

Interrupt rating

15 kAIC

Catalog Number

FAZ-C16/3

Type

UL 1077 Industrial miniature circuit breaker - supplementary protector

Warranty

1 year

Application

Suitable for applications where medium levels of inrush current are expected

Product Weight

.8 lb

Amperage

16 amperes

Terminal Type

Standard Terminals

Number of Poles

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
