FAZ-C25/1-DC Eaton Electronic Components

FAZ-C25/1-DC on Powermatic Associates
Eaton

Part#:FAZ-C25/1-DC

Manufacturer:Eaton

Category:Electronic Components

Product Lifecycle:Active

Product description

Eaton FAZ supplementary protector,UL 489 Industrial miniature circuit breaker - supplementary protector,Medium levels of inrush current are expected,25 A,10 kAIC,Single-pole,125 Vdc per pole,5-10X /n,50-60 Hz,Standard terminals,C Curve

Product Details

  • Number of Poles
    1 Pole
  • Current Rating
    25 A
  • Trip Curve
    C
  • SCCR
    10 kA
  • UL Standard
    489
  • UL CCN
    DIVQ
  • UL File No.
    E235139
  • Terminal Type
    Ring Tongue
  • EAN
    4015082791308
  • Type
    UL 489 Industrial miniature circuit breaker - supplementary protector
  • Circuit protection
    C curve
  • Product Height
    4.13 in
  • Application
    Suitable for applications where medium levels of inrush current are expected
  • Catalog Number
    FAZ-C25/1-DC
  • Frequency rating
    50-60 Hz
  • Trip Type
    5-10X /n
  • Certifications
    UL 489 CSA Std. C22.2 No. 235
  • Terminals
    Standard
  • Product Name
    Eaton FAZ supplementary protector
  • Interrupt rating
    10 kAIC
  • Warranty
    1 year
  • Catalog Notes
    Positioned for medium inrush startup currents to provide protection for small transformers and pilot devices.
  • Product Length/Depth
    .7 in
  • Voltage rating
    125 Vdc
  • Number of poles
    Single-pole
  • Product Weight
    1 lb
  • Product Width
    2.97 in
  • Amperage Rating
    25 A

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
