FAZ-D1/3N Eaton Miniature Circuit Breakers (MCBs)
Part#:FAZ-D1/3N
Manufacturer:Eaton
Category:Miniature Circuit Breakers (MCBs)
Product Lifecycle:Active
Product description
FAZ-D1/3N Eaton - UL 1077 Industrial Miniature Circuit Breaker - Supplementary Protector
Product Details
- Number of Poles 3 Pole
- Current Rating 1 A
- Trip Curve D
- SCCR 5 kA
- UL Standard 1077
- UL CCN QVNU2
- UL File No. E177451
- Terminal Type Compression
- Catalog Notes Magnetic range for higher startup inrush levels that are usually seen in motors and transformers, and other high inductive systems.
- Product Length/Depth 2.76 in
- Frequency rating 50-60 Hz
- EAN 4015082789831
- Terminals Standard
- Warranty 1 year
- Amperage Rating 1 A
- Product Name Eaton FAZ supplementary protector
- Interrupt rating 15 kAIC
- Certifications IEC 60947-2 CSA Std. C22.2 No.235 UL 1077
- Application Suitable for applications where high levels of inrush current are expected
- Product Height 3.25 in
- Type UL 1077 Industrial miniature circuit breaker - supplementary protector
- Product Width 3 in
- Number of poles Three-pole + N
- Catalog Number FAZ-D1/3N
- Circuit protection D curve
- Product Weight 1 lb
- Trip Type 10-20X /n
- Terminal Type Standard Terminals
- Amperage 1 ampere
- Number of Poles 3
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
FAZ-D1/3N Related Documents
Similar products from: Eaton Miniature Circuit Breakers (MCBs)
Manufacturer warranty
FAZ-D1/3N Eaton
Get a quick Quote!
Request a quote, and we will send you price and availability within minutes.
Select Qty:
Average response time: 11 minutes
Worldwide Shipping and Delivery
Secure Payment Processing
Warranty
Responsive Customer Support
Got Questions? We've Got Answers!
Need more details?
Feel free to chat with us
Compare FAZ-D1/3N with other Miniature Circuit Breakers (MCBs) products
Number of Poles
Current Rating
Trip Curve
SCCR
UL Standard
UL CCN
UL File No.
Terminal Type
Catalog Notes
Product Length/Depth
Selected product
FAZ-D1/3N
Eaton
FAZ-D1/3N Eaton - UL 1077 Industrial Miniature Circuit Breaker - Supplementary Protector
Number of Poles3 Pole
Current Rating1 A
Trip CurveD
SCCR5 kA
UL Standard1077
UL CCNQVNU2
UL File No.E177451
Terminal TypeCompression
Catalog NotesMagnetic range for higher st...
Product Length/Depth2.76 in
Number of Poles1 Pole
Current Rating15 A
Trip CurveD
SCCR10 kA
UL Standard489
UL CCNDIVQ
UL File No.E305318
Terminal TypeCompression
Catalog Notes-
Product Length/Depth-
Number of Poles1 Pole
Current Rating10 A
Trip CurveC
SCCR14 kA
UL Standard489
UL CCNDIVQ
UL File No.E212323
Terminal TypeCompression
Catalog Notes-
Product Length/Depth-
About the manufacturer
Powermatic Associates is an authorized Eaton distributor, proudly partnering with a global leader in power management solutions to bring our customers innovative and reliable products. Eaton is renowned for its comprehensive range of products and services designed to enhance electrical, hydraulic, and mechanical power efficiency, reliability, and safety. By incorporating Eaton's cutting-edge techn...
About the Product Category
An MCB is an automatically operated electrical switch. Miniature circuit breakers are intended to prevent damage to an electrical circuit as a result of excess current.
