FAZ-K25/3 Eaton Electronic Components

FAZ-K25/3 on Powermatic Associates
Eaton

Part#:FAZ-K25/3

Manufacturer:Eaton

Category:Electronic Components

Product Lifecycle:Active

Product description

Eaton FAZ supplementary protector,UL 1077 Industrial miniature circuit breaker - supplementary protector,25 A,15 kAIC,Three-pole,8-12X /n,Standard terminals,K curve

Product Details

  • Number of Poles
    3 Pole
  • Current Rating
    25 A
  • Trip Curve
    K
  • SCCR
    5 kA
  • UL Standard
    1077
  • UL CCN
    QVNU2
  • UL File No.
    E177451
  • Terminal Type
    Compression
  • Catalog Number
    FAZ-K25/3
  • Trip Type
    8-12X /n
  • Warranty
    1 year
  • EAN
    4015082789138
  • Number of poles
    Three-pole
  • Product Weight
    1 lb
  • Amperage Rating
    25 A
  • Product Length/Depth
    3.5 in
  • Product Name
    Eaton FAZ supplementary protector
  • Product Height
    2 in
  • Product Width
    3 in
  • Catalog Notes
    Applications suited for highly inductive loads. Similar to D but with a more narrow range.
  • Certifications
    IEC 60947-2 UL 1077 CSA Std. C22.2 No.235
  • Terminals
    Standard

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
