FDB2080N06 Eaton Industrial Automation Components

FDB2080N06 on Powermatic Associates
Eaton

Part#:FDB2080N06

Manufacturer:Eaton

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

FDB2080N06 Eaton - Eaton Series C complete molded case circuit breaker, F-frame, FDB, Fixed thermal, fixed magnetic trip, Two-pole, 80A, 600 Vac, 250 Vdc, 18 kAIC at 240 Vac, 14 kAIC at 480 Vac, Load side, 24 Vdc rear with right pigtail, 50/60 Hz

Product Details

  • Weight
    3 pounds
  • Number of Poles
    2
  • Terminal Type
    Load Side
  • Interrupt Rating
    18 kiloamps, 240 volts
  • Length
    3.38 inches
  • Height
    6 inches
  • Frequency
    50 hertz, 60 hertz
  • Amperage
    80 amperes
  • Frequency rating
    50/60 Hz
  • Shunt trip
    24 Vdc right pigtail rear low energy
  • Circuit breaker type
    FDB
  • Interrupt rating
    18 kAIC at 240 Vac 14 kAIC at 480 Vac
  • Series
    Series C
  • Number of poles
    Two-pole
  • Amperage Rating
    80 A
  • Trip Type
    Fixed Magnetic, Fixed Thermal
  • Voltage rating
    600 Vac, 250 Vdc
  • Terminals
    Load side
  • Circuit breaker frame type
    Complete breaker
  • Frame
    F
  • Product Name
    Eaton Series C complete molded case circuit breaker
  • UPC
    782116058044
  • Product Weight
    3 lb
  • Certifications
    UL Listed
  • Warranty
    Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
  • Product Width
    2.75 in
  • Product Length/Depth
    3.38 in
  • Product Height
    6 in
  • Catalog Number
    FDB2080N06

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
