GEE3100FFG Eaton Industrial Automation Components

GEE3100FFG on Powermatic Associates
Eaton

Part#:GEE3100FFG

Manufacturer:Eaton

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Eaton Series G molded case circuit breaker, EG-frame, EG, Fixed thermal, Fixed magnetic trip, Three-pole, 100 A, 600Y/347 Vac, 35 kA at 240 Vac, 25 kA at 480 Vac, 18 kA at 600Y/347 Vac, Line and load, 50/60 Hz

Product Details

  • Interrupting Rating:
    35 kA at 240 Vac, 25 kA at 480 Vac, 18 kA at 600Y/347 Vac, Line and load, 50/60 H
  • Shipping Weight:
    2.80
  • Shipping Length:
    7.00 In.
  • Shipping Width:
    4.00 In.
  • Current Rating:
    100 A
  • Frame Type:
    EG
  • Number of Poles:
    3
  • Voltage Rating:
    480 V
  • UPC:
    67385949
  • Shipping Height:
    4.00 In.

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
