PDG24G0060E2ZN Eaton Molded Case Circuit Breakers (MCCB)

PDG24G0060E2ZN on Powermatic Associates
Eaton

Part#:PDG24G0060E2ZN

Manufacturer:Eaton

Category:Molded Case Circuit Breakers (MCCB)

Product Lifecycle:Active

Product description

Eaton Power Defense molded case circuit breaker, Globally Rated, Frame 2, Four Pole (100% N), 60A, 35kA/480V, PXR20 LSI w/ ZSI and Relays, No Terminals

Product Details

  • Product Length/Depth
    88.9 mm
  • Certifications
    IEC 60947-2 CCC Marked UL 489 CSA
  • Catalog Number
    PDG24G0060E2ZN
  • Interrupt rating
    35 kAIC at 480 Vac
  • Circuit breaker type
    PD2 Global
  • Class
    Class A
  • Compliances
    RoHS Compliant
  • Voltage rating - max
    600 V
  • Product Width
    139.5 mm
  • Rated operation voltage (Ue) at AC - max
    600
  • Interrupt rating range
    18 kAIC @600V (UL/CSA) 20 kAIC Icu/ 15/13 kAIC Ics/ 42 kAIC Icm @525V South Africa (IEC) 10 kAIC Icu @250 Vdc 10 kAIC Icu @125 Vdc 55 kAIC Icu/ 55 kAIC Ics/ 121 kAIC Icm @240V (IEC) 8 kAIC Icu/ 4 kAIC Ics/ 16.8 kAIC Icm @690V (IEC) 25 kAIC Icu/ 20 k
  • Frame
    2
  • Product Name
    Eaton Power Defense molded case circuit breaker
  • Number of poles
    Four-pole (100% N)
  • Voltage rating
    600 Vac
  • Product Height
    152.4 mm
  • Amperage Rating
    60 A
  • Protection
    100% neutral protection
  • UPC
    786679203811
  • Special features
    ZSI / Relays
  • Circuit breaker frame type
    Complete breaker
  • Terminals
    No Terminals
  • Product Weight
    2.46 kg
  • Trip rating
    60 A
  • Warranty
    Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
  • Switch off technique
    Electronic
  • Trip Type
    PXR 20 LSI

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
