18698 Festo Cable Assemblies
Part#:18698
Alt. Part#:KMP3-9P-08-5
Manufacturer:Festo
Category:Cable Assemblies
Product Lifecycle:Active
Product description
connecting cable KMP3-9P-08-5 For valve terminal CPV. Based on the standard: DIN 41652, Cable identification: with accessories, Connection frequency: 50, Product weight: 425 g, Electrical connection 1, function: Field device side
Product Details
- Product weight 425 g
- Electrical connection 1, connection technology Sub-D
- Type code KMP3
- Contact durability 50
- Electrical connection 1, cable outlet Angled
- Electrical connection for input 1, connection pattern 00995638
- Electrical connection 2, number of pins/wires 10
- Nominal operating voltage DC 24 V
- Electrical connection 1, type of mounting 2x M3 screw
- Electrical connection 2, connection type Cable
- Electrical connection 2, occupied pins/wires 9
- Cable length 5 m
- Bending radius, flexible cable installation ≥ 75 mm
- Cable diameter tolerance ± 0.3 mm
- Nominal conductor cross section 0.34 mm²
- CE marking (see declaration of conformity) As per EU RoHS directive
- Color cable sheath Gray
- Housing material PA
- Cable designation With accessories
- Electrical connection 1, design Rectangular
- Electrical connection 1, number of pins/wires 9
- Electrical connection 2, connection technology Open end
- Surge resistance 1 kV
- Bending radius, fixed cable installation ≥ 30 mm
- Cable design 10 x 0.34 mm²
- Storage temperature -25 °C ... 75 °C
- Based on norm DIN 41652
- Electrical connection 1, function Field device end
- Electrical connection 1, connection type Socket
- Electrical connection 1, occupied pins/wires 9
- Current rating at 40°C 3 A
- Degree of protection IP65
- Ambient temperature -25 °C ... 70 °C
- Note on materials RoHS-compliant
- Electrical connection 2, function Control side
- DC operating voltage range 0 V ... 30 V
- Cable characteristic Standard
- Cable diameter 7.15 mm
- Wire ends Cut off bluntly
- Ambient temperature with flexible cable installation -5 °C ... 70 °C
- Material of cable sheath PVC
- Connector cable test conditions Test conditions on request
- Note on degree of protection In mounted state
- Contamination level 3
- Material of pin contacts Copper alloy, gold-plated
- Seals material NBR
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
