564189 Festo Cable Assemblies

Product Details

• Cable designation
  Without label holder
• Product weight
  47 g
• Electrical connection 1, design
  Round
• Electrical connection 1, cable outlet
  Straight
• Electrical connection 1, type of mounting
  Screw-type lock with AF 14 and longitudinal knurl
• Electrical connection 2, cable outlet
  Straight
• DC operating voltage range
  0 V ... 30 V
• Cable characteristic
  Standard
• Bending radius, flexible cable installation
  ≥ 56 mm
• Nominal conductor cross section
  0.14 mm² 0.75 mm²
• Ambient temperature
  -25 °C ... 70 °C
• Contamination level
  3
• Material of cable sheath
  TPE-U(PUR)
• Type code
  NEBC
• Electrical connection 1, function
  Field device end Control side
• Electrical connection 2, function
  Field device end Control side
• Electrical connection 2, connection technology
  M12x1, with Festo-specific coding
• Electrical connection 2, type of mounting
  Screw-type lock with AF 14 and longitudinal knurl
• Note on acceptable current load at 40°C
  1.5 A for conductor cross-section of 0.14 mm²
• Cable length
  0.25 m
Based on norm
Dimensions as per EN 61076-2-101
Contact durability
100
Electrical connection 1, connection type
Hybrid plug
Electrical connection 1, number of pins/wires
8
Electrical connection 2, design
Round
Electrical connection 2, number of pins/wires
8
Current rating at 40°C
7 A
Connector cable test conditions
Test conditions on request
Cable diameter
8 mm
Cable design
(1 x (4 x 0.14 mm²)) + 4 x 0.75 mm²
Note on degree of protection
In mounted state
Storage temperature
-40 °C ... 70 °C
Housing material
TPE-U(PUR)
Color cable sheath
Light gray
Certification
c UL us - Recognized (OL)
Electrical connection 1, connection technology
M12x1, with Festo-specific coding
Material of screw-type lock
Brass, nickel-plated
Electrical connection 1, occupied pins/wires
8
Electrical connection 2, connection type
Hybrid plug
Electrical connection 2, occupied pins/wires
8
Surge resistance
0.8 kV
Bending radius, fixed cable installation
≥ 24 mm
Degree of protection
IP65 IP67
Special features
Oil-resistant
Ambient temperature with flexible cable installation
-5 °C ... 70 °C
Housing colour
Black
Insulating sheath material
PP
Cable diameter tolerance
± 0.2 mm
Note on materials
RoHS-compliant Halogen-free
Corrosion resistance class (CRC)
1 - Low corrosion stress
Material of pin contacts
Brass, gold-plated
