566727 Festo Pneumatic Valves Accessories

566727 on Powermatic Associates
Festo

Part#:566727

Alt. Part#:VAVE-L1-1L2-LR

Manufacturer:Festo

Category:Pneumatic Valves Accessories

Product Lifecycle:Active

Product description

electrical connection box VAVE-L1-1L2-LR Polarity protected: for operating voltage, Additional functions: (* Spark arresting, * Reduction of holding current), Signal status display: LED, Nominal operating voltage DC: 24 V, Surge strength: 0,8 kV

Product Details

  • Housing material
    PA
  • Type code
    VAVE
  • Nominal operating voltage DC
    24 V
  • Connection cross section
    0.14 mm²
  • Mounting position
    Any
  • Signal status display
    LED
  • Contamination level
    3
  • CE marking (see declaration of conformity)
    As per EU EMC directive
  • Product weight
    7.8 g
  • Protective earth connection
    Not available
  • Note on materials
    RoHS-compliant
  • Surge resistance
    0.8 kV
  • Reverse polarity protection
    for operating voltage
  • Corrosion resistance class (CRC)
    0 - No corrosion stress
  • Ambient temperature
    -5 °C ... 60 °C
  • Electrical connection
    Flying lead
  • Type of mounting
    Clip
  • Additional functions
    Spark suppression Holding current reduction
  • Degree of protection
    IP40
  • Certification
    RCM compliance mark
  • Cable length
    1 m
  • Housing colour
    Black

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
