8032627 Festo Cable Assemblies

Product Details

• Additional functions
  Protective circuit
• Product weight
  440 g
• Electrical connection 1, connection technology
  Connection diagram type C as per EN 175301-803
• Electrical connection 2, function
  Control side
• Electrical connection 1, information on cable outlet
  Can be rotated through 180°
• Cable designation
  Without label holder
• Electrical connection 1, design
  Rectangular
• Electrical connection 1, number of pins/wires
  4
• Electrical connection 2, number of pins/wires
  2
• Current rating at 40°C
  6 A
• Cable diameter tolerance
  ± 0.1 mm
• Ambient temperature
  -20 °C ... 70 °C
• CE marking (see declaration of conformity)
  As per EU RoHS directive
• Color cable sheath
  Gray
• Material of pin contacts
  Copper alloy, tin-plated
• Signal status display
  LED yellow
• Contact durability
  50
• Electrical connection 1, cable outlet
  Angled
• Electrical connection for input 1, connection pattern
  00995797
• Electrical connection 2, connection technology
  Open end
Nominal operating voltage DC
24 V
Protective earth connection
Not available
Cable diameter
5.2 mm
Nominal conductor cross section
0.75 mm²
Note on materials
RoHS-compliant
Housing material
TPE-U(PU)
Material of screws
Stainless steel
Electrical connection 1, connection type
Socket, narrow
Electrical connection 1, occupied pins/wires
2
Electrical connection 2, occupied pins/wires
2
Surge resistance
2.4 kV
Cable characteristic
Standard
Bending radius, flexible cable installation
≥ 52 mm
Note on degree of protection
In mounted state
Ambient temperature with flexible cable installation
-5 °C ... 70 °C
Material of cable sheath
PVC
Insulating sheath material
PVC
Type code
NEBV
Electrical connection 1, function
Field device end
Electrical connection 1, type of mounting
On air solenoid valve with M2.5 central screw
Electrical connection 2, connection type
Cable
Cable length
10 m
Connector cable test conditions
Test conditions on request
Degree of protection
IP65 IP67
Corrosion resistance class (CRC)
3 - High corrosion stress
Seals material
HNBR
DC operating voltage range
20.4 V ... 26.4 V
Reverse polarity protection
Bipolar
Cable design
2 x 0.75 mm²
Contamination level
3
Housing colour
Black
