8085741 Festo Cable Assemblies
Part#:8085741
Alt. Part#:NEBC-M12G5-S-1,5-N-M12G5
Manufacturer:Festo
Category:Cable Assemblies
Product Lifecycle:Active
Product description
connecting cable NEBC-M12G5-S-1,5-N-M12G5 Cable identification: with accessories, Connection frequency: 500, Product weight: 163 g, Electrical connection 1, function: Field device side, Electrical connection 1, design: Round
Product Details
- Contact durability 500
- Electrical connection 1, design Round
- Electrical connection 1, occupied pins/wires 5
- Electrical connection 2, cable outlet Straight
- Electrical connection 2, type of mounting Screw-type lock
- Operating voltage range AC 0 V ... 30 V
- Cable characteristic Standard
- Cable design 4 x 0.34 mm² Shielded
- Note on degree of protection In mounted state
- Housing material TPE-U(PUR)
- Material of pin contacts Bronze, gold-plated Brass, gold-plated
- Cable designation With accessories
- Product weight 163 g
- Electrical connection 1, connection technology M12x1 A-coded as per EN 61076-2-101
- Electrical connection for input 1, connection pattern 00995383
- Electrical connection 2, number of pins/wires 5
- Surge resistance 0.8 kV
- Cable diameter 5 mm
- Ambient temperature -25 °C ... 70 °C
- Ambient temperature with flexible cable installation -5 °C ... 70 °C
- Material of cable sheath TPE-U(PUR)
- Insulating sheath material PVC
- Electrical connection 1, function Field device end
- Electrical connection 1, cable outlet Straight
- Electrical connection 1, type of mounting Screw-type lock
- Electrical connection 2, connection type Plug
- Electrical connection 2, occupied pins/wires 5
- Electrical connection 1, connection type Plug
- Electrical connection 2, function Control side
- Electrical connection 2, connection technology M12x1 A-coded as per EN 61076-2-101
- Electrical connection 2, connection pattern 00995383
- Current rating at 40°C 4 A
- Connector cable test conditions Test conditions on request
- Nominal conductor cross section 0.34 mm²
- Contamination level 3
- Color cable sheath Light gray
- Material of screw-type lock Brass, nickel-plated
- Type code NEBC
- Electrical connection 1, number of pins/wires 5
- Electrical connection 2, design Round
- DC operating voltage range 0 V ... 30 V
- Cable length 1.5 m
- Degree of protection IP65 IP67
- Note on materials RoHS-compliant
- Corrosion resistance class (CRC) 2 - Moderate corrosion stress
- Housing colour Black
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
