PN10-14R-D Panduit Industrial Automation Components

Product Details

• Wire Strip Length (mm)
  7.1
• Maximum Copper Conductor Size (AWG STR)
  #10
• Minimum Copper Conductor Size (AWG SOL)
  #12
• Wire Strip Length (In.)
  9/32
• Flammability Rating
  UL94-HB
• Tongue Width (In.)
  0.52
• Stud Hole Size (In.)
  1/4
• Maximum Metric Conductor Size (mm²)
  6
• Maximum Voltage (kV)
  0.6
• Overall Length (mm)
  30.7
• Packaging Type
  Box
• Color Code
  Yellow
• Maximum Operating Temperature (°F)
  221
• Insulation Material
  Nylon
• Minimum Metric Conductor Size (mm²)
  4
• Finish/Coating
  Tin-Plated
• Overall Width (In.)
  0.52
• Minimum Copper Conductor Size (AWG STR)
  #12
• Maximum Voltage (V)
  600
• Overall Length (In.)
  1.21
Tongue Width (mm)
13.2
Maximum Wire Size (AWG)
#10
Barrel Type
Grip Sleeve
Maximum Wire Insulation Diameter (In.)
0.225
Tongue Thickness (mm)
1.02
Maximum Copper Conductor Size (AWG SOL)
#10
Base Material
Copper
Maximum Wire Insulation Diameter (mm)
5.72
Tongue Thickness (In.)
0.04
Minimum Wire Size (AWG)
#12
Standards Met
UL 486A/B, and CSA 22.2 No.65
Sub Brand
Pan-Term®
Product Type
Loose Piece Ring Terminal
Maximum Operating Temperature (°C)
105
Overall Width (mm)
13.2
For Use With
CT-100, CT-1550, CT-1551, CT-2300/ST (CD-550), CT-2500/L (CT-2550CH), UP14ZLW (CD-550)
Part Features
• Ring tongue design assures a secure connection in high vibration applications • Metal insulation grip sleeve crimps to wire insulation, providing protection to the crimp joint during high vibration applications • Internal barrel serrations assure goo
