302MC-N-ST Red Lion Industrial Automation Components

302MC-N-ST on Powermatic Associates
Red Lion

Part#:302MC-N-ST

Manufacturer:Red Lion

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Red Lion 302MC-N-ST is a media converter designed to facilitate communication between different media types, specifically converting signals between copper wires and fiber optic cables. It operates on a supply voltage range of 10-30Vdc, accommodating both 12Vdc and 24Vdc systems. The device features a single RJ45 port for 10/100BaseTX connections and a fiber optic ST connector that supports multi-mode fiber with a rated optical fiber length of up to 2km for 100BaseFX transmissions. It incorporates N-View monitoring technology for enhanced network visibility and is housed in a metal case suitable for DIN rail mounting. The 302MC-N-ST is designed to operate within an ambient air temperature range for storage of -40 to +70 degrees Celsius. Its construction includes Normally Closed (NC) auxiliary contacts, emphasizing its utility in industrial settings. The product is part of the N-Tron 302MC series.

Product Details

  • Design
    N-View monitoring Copper / FO Fiber optic converter
  • Equivalent to
    302MCNST
  • Secondary brand
    N-Tron
  • Supply voltage (DC)
    10-30Vdc (12Vdc / 24Vdc)
  • Order code / Manufacturer SKU
    302MC-N-ST
  • Primary brand
    Red Lion
  • Main function
    Media converter
  • Material
    Metal case
  • Functions
    Media converter
  • Ambient air temperature for operation
    -40...+70 °C
  • Product series / family name
    Converters
  • Connection type
    1 x RJ45 port (10/100BaseTX) 1 x Fiber optic ST connector (multi-mode; 100BaseFX; 2km rated optical fiber)
  • Compliant with standard(s)
    CE
  • Sub-range name
    N-Tron 302MC series
  • Mounting mode
    DIN rail

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

302MC-N-ST Related Documents

Red Lion - N-Tron 300 Series Unmanaged switches - Installation Guide.pdf
