302MCE-N-SC-15 Red Lion Industrial Automation Components

302MCE-N-SC-15 on Powermatic Associates
Red Lion

Part#:302MCE-N-SC-15

Manufacturer:Red Lion

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Red Lion 302MCE-N-SC-15 is a media converter designed to facilitate communication between different media types, specifically converting signals between copper (RJ45 port, 10/100BaseTX) and fiber optic (SC connector, single-mode, 100BaseFX) interfaces over a distance of up to 15km. It operates on a supply voltage range of 10-30Vdc, accommodating both 12Vdc and 24Vdc systems. This component features N-View monitoring for enhanced network visibility and is housed in a metal case suitable for DIN rail mounting. The ambient air temperature range for storage is specified from -40 to +70 degrees Celsius, ensuring its durability in various environmental conditions. The technology used in this component includes Normally Closed (NC) auxiliary contacts, emphasizing its utility in industrial settings.

Product Details

  • Primary brand
    Red Lion
  • Functions
    Media converter
  • Material
    Metal case
  • Compliant with standard(s)
    CE
  • Secondary brand
    N-Tron
  • Product series / family name
    Converters
  • Mounting mode
    DIN rail
  • Ambient air temperature for operation
    -40...+70 °C
  • Main function
    Media converter
  • Design
    N-View monitoring Copper / FO Fiber optic converter
  • Order code / Manufacturer SKU
    302MCE-N-SC-15
  • Equivalent to
    302MCENSC15
  • Supply voltage (DC)
    10-30Vdc (12Vdc / 24Vdc)
  • Connection type
    1 x RJ45 port (10/100BaseTX) 1 x Fiber optic SC connector (single-mode; 100BaseFX; 15km rated optical fiber)
  • Sub-range name
    N-Tron 302MC series

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

302MCE-N-SC-15 Related Documents

Red Lion - N-Tron 300 Series Unmanaged switches - Installation Guide.pdf
