PAXTM010 Red Lion Industrial Automation Components

PAXTM010 on Powermatic Associates
Red Lion

Part#:PAXTM010

Manufacturer:Red Lion

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Red Lion PAXTM010 is a digital timer from the PAX series, designed with a 1/8 DIN (96x48mm) form factor and features 14.2mm green digits with communication capability. It operates on a supply voltage range of 85-250Vac, accommodating various standard voltages such as 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac. The device is equipped with three digital inputs (Sink/Source) for user input and offers a degree of protection rated at IP65 NEMA 4X, ensuring its suitability for a wide range of industrial applications. Its dimensions are specified as 1/8 DIN horizontal, measuring W96mm x H48mm (3.80" x 1.95").

Product Details

  • Primary brand
    Red Lion
  • Display
    1 row x 6-digits red characters (14.2mm / 0.56" high) LED display
  • Order code / Manufacturer SKU
    PAXTM010
  • Sub-range name
    PAX series
  • Digital inputs
    3 x digital inputs (Sink/Source) (USER INPUT)
  • Main function
    Timer (Digital)
  • Functions
    Digital timer
  • Dimensions
    1/8 DIN horizontal (W96mm x H48mm / 3.80" x 1.95")
  • Product series / family name
    Process timers
  • Design
    1/8 DIN (96x48mm) 14.2mm red digits communication capability
  • Compliant with standard(s)
    CE IEC 60068-2-6 (vibration) EN 61326-1 immunity to industrial locations EN 61010-1 EN 61010-2-030 UL Listed RoHS compliant
  • Supply voltage (DC)
    11-36Vdc (12Vdc / 24Vdc)
  • Degree of protection
    IP65 NEMA 4X

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
