Part#:725AXXSC3ML-24D

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

Harmony, Power relay, DIN rail/panel mount, 30 A, LED test button, screw terminals, 24 V DC, 1 NO

Product Details

  • Contact Composition
    1 NO
  • Product Type
    DIN rail/panel mount relay
  • Dielectric Strength
    4000 V AC between coil and contact
  • Rated Power In W
    1.5 kW 120 V tungsten
  • Nominal Input Voltage
    19.2...26.4 V DC
  • Network Frequency
    50/60 Hz
  • Class Number
    725
  • Drop-Out Voltage Threshold
    DC
  • Local Signalling
    LED indicator test button
  • Mechanical Durability
    5000000 cycles
  • Contacts Material
    Silver alloy contacts
  • Product Range
    Harmony Electromechanical Relays
  • [In] Rated Line Current
    30 A
  • Coil Resistance
    300 Ohm
  • Response Time
    30 ms
  • Control Type
    Test button
  • Electrical Durability
    100000 cycles resistive IEC
  • Series Name
    Power
  • Average Coil Consumption
    1.90 W
  • Minimum Switching Current
    100 mA 5 V DC
  • Net Weight
    4.23 oz (120 g)
  • Maximum Switching Voltage
    240 V CE 277 V UL
  • Connections - Terminals
    Screw coil terminal M3.5 Screw contact terminal M4
  • Rated Power In Hp
    3 hp 277 V AC 1.5 hp 120 V AC
  • Mounting
    DIN rail Flange
  • Tightening Torque
    10.6...15 lb.in 1.2...1.7 N.m
  • [Ie] Rated Operational Current
    30 A at 277 V AC (on resistive load) conforming to UL 30 A at 240 V AC (general purpose) conforming to UL 30 A at 30 V DC (on resistive load) conforming to UL 30 A at 240 V AC (on resistive load) conforming to IEC 30 A at 28 V DC (on r

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
