Powermatic Associates Logo

8502-PD3.10E-V06 Schneider Electric Industrial Automation Components

8502-PD3.10E-V06 on Powermatic Associates
Schneider Electric

Part#:8502-PD3.10E-V06

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D 8502-PD3.10E-V06 Other Contactors EA

Product Details

  • Shipping Width:
    3.00 In.
  • Shipping Length:
    4.00 In.
  • Shipping Weight:
    0.80 lbs.
  • Shipping Height:
    3.00 In.

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
