8502SAO11V08 Schneider Electric Electronic Components

8502SAO11V08 on Powermatic Associates
Schneider Electric

Part#:8502SAO11V08

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

NEMA Contactor, Type S, nonreversing, Size 00, 9A, 1 HP at 230 VAC, 1 phase, up to 100 kA, 2 pole, 208 VAC coil, open

Product Details

  • Contactor Type
    Non-reversing
  • Number Of Poles
    2P
  • Height
    4.34 in (110.24 mm)
  • Pilot Light
    No indicator
  • NEMA Size
    00
  • Control Circuit Type
    Common control circuit
  • Depth
    4.22 in (107.19 mm)
  • Maximum Voltage Rating
    600 V AC
  • Auxiliary Contacts
    Without
  • Product Range
    8502S
  • Terminal Type
    Screw clamp terminals
  • Phase
    1 phase
  • Coil Voltage
    208 V AC 60 Hz
  • Product Type
    Contactor
  • Control Units
    No control units
  • Width
    3.22 in (81.79 mm)
  • Rated Current
    9 A
  • Other Equipment
    Fuse not supplied
  • Horsepower Rating
    0.33 HP 115 V AC 1 HP 230 V AC
  • SCCR
    Circuit-breaker 70 A maximum, SCCR: 100 kA at 480 V AC Fuse J 60 A maximum, SCCR: 100 kA at 600 V AC Fuse T 60 A maximum, SCCR: 100 kA at 600 V AC Fuse RK1 60 A maximum, SCCR: 100 kA at 600 V AC Fuse RK5 60 A maximum, SCCR: 100 kA at 6

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
