Part#:8536SEW11V07

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

NEMA Motor Starter, Type S, nonreversing, Size 3, 90A, 50 HP at 460 VAC, 5 kA SCCR, 3 phase, 3 pole, melting alloy, 600 VAC coil, NEMA 4/4X

Product Details

  • Product Type
    Motor starter
  • Product Range
    S
  • Depth
    9.56 in (242.82 mm)
  • Starter Type
    Non reversing
  • Number Of Poles
    3P
  • Pilot Light
    Without pilot light
  • NEMA Size
    3
  • Width
    18.16 in (461.26 mm)
  • Phase
    3 phase
  • Terminal Type
    Screw clamp terminals
  • Type Of Overload
    Melting alloy 3
  • Auxiliary Contacts
    Without
  • Maximum Voltage Rating
    600 V AC
  • Control Circuit Type
    Common control circuit
  • Height
    32.22 in (818.39 mm)
  • Control Units
    No control units
  • Rated Current
    90 A
  • SCCR
    Circuit-breaker: 5 kA at 600 V AC Fuse: 5 kA at 600 V AC
  • Coil Voltage
    550 V AC 50 Hz 600 V AC 60 Hz
  • Horsepower Rating
    25 HP 200 V AC 30 HP 230 V AC 50 HP 460 V AC 50 HP 575 V AC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

8536SEW11V07 Related Documents

Instruction Sheet-1631029555880.pdfProduct Datasheet-1631029555892.pdfCatalog-1631029555890.pdf

Similar products from: Schneider Electric Electronic Components
