8538SBA11S8V02S Schneider Electric Electronic Components

8538SBA11S8V02S on Powermatic Associates
Schneider Electric

Part#:8538SBA11S8V02S

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

NEMA Combination Starter, Type S, nonfusible disconnect, Size 0, 18A, 5 HP at 600 VAC polyphase, 120 VAC coil, NEMA 12

Product Details

  • NEMA Size
    0
  • Depth
    8.34 in (211.84 mm)
  • Width
    9.5 in (241.30 mm)
  • Device Mounting
    Surface
  • Reset
    Without external
  • Contactor Application
    Non-reversing
  • Number Of Thermal Units Required
    3
  • Net Weight
    40 lb(US) (18.14 kg)
  • Device Short Name
    S
  • Number Of Poles
    3
  • Height
    24 in (609.60 mm)

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
